Active Balancer - Lifepo4 Lithium Battery Equaliser

SPECIFICATIONS

Product Name: Battery Balancer

Brand Name: QUCC

Model Number: Q-4S-24SPHQ

Accessory Type: Battery Accessories

Origin: China

Cell Type: 3.2V, 3.6V, 3.7V, LTO(2.2V)

Battery Type: LiFePO4, Li-ion, Lithium Titanate battery

Support String: 4S-200S

Before Use:

Note * unplug the port before connecting the cable. After connecting, test whether there is a connection error. The wrong connection will immediately blow the fuse and seriously damage the chip.

Tips: 17S balancer will be updated with new size. All orders for 17S balancer from December 8/ 2023 will be sent with new dimensions: 125mmx88mmx28mm ± 2mm

Product features

• Can be connected in series
• Can be connected in parallel

Suitable Capacity: Capacity above 50AH

Balanced Mode: Manual balancing, automatic balancing

Compatible Capacity: 50A 100A 150A 200A 250A 300A 350A 400A 450A 500A

Suggested Number Of Balancers: 1 balancer below 200A

Recommended Number Of Balancers: 2 balancers in parallel above 200A

____________________

About Use: Fixed inside the battery pack

Protection functions

• Low voltage protection, automatic sleep
• High voltage protection, automatic sleep
• High temperature protection, automatic sleep
• Over-current protection, auto-sleep

Important Information Before Use:

The balancer is designed to balance the voltage difference between batteries, extending their service life. It does not function as a standalone battery protector; the charger and Battery Management System (BMS) serve as the primary safeguards. It will not damage the battery; in case of abnormalities, check the battery's condition, BMS compatibility, and charger alignment.

Two modes are available:

A) Sleep Function (Default): Automatically turns off balancing when battery voltage falls below 3V.
B) Non-Sleep Function: Active balancing is constant and does not enter sleep mode.

Note: The balancer may not light up blue if the cell voltage difference is less than 0.05V, and the total voltage of the first four cells is below 11V.

If the balancer is in the ON mode, it will rest for 1-2 hours after balancing, and the blue light will turn off after about 12 hours, even with a pressure difference.

It will passively go to sleep; if this mode is a concern, it's recommended to keep the button set to OFF.

Example Scenarios:

The balancer turns on when the first battery voltage exceeds 3V; otherwise, it turns off.
It balances when the total voltage of the 1st to 4th cells exceeds 11V, or if the voltage difference is greater than 0.05V.
Please do not solely rely on the balancer's LED status to determine its working status. To check if it's operational:

Ensure the hardware fuse is intact.
Verify if voltage passes through the balancer normally.
Use a clamp current meter to test for balance current (requires specific conditions).
After installation, test the normal voltage passage through each battery. Incorrect voltages can result in smoking or burning out the balancer upon power-up. Confirm the correct insertion and unplugging order before operation, as damage from incorrect sequencing or wiring is not covered by warranty.

For newly assembled battery packs, the balancer complements the BMS by providing additional balancing current, enhancing battery life. However, it is not suitable for repairing old batteries with large internal resistance and capacity differences. Replacement is recommended for such batteries, as professional balancers may struggle to address persistent voltage imbalances during charging.
