800W pure sine wave solar power inverter DC 12-48V to AC 110V/220V
800W pure sine wave solar power inverter DC 12-48V to AC 110V/220V
Couldn't load pickup availability
CE
SPECIFICATIONS
Type: DC/AC Inverters
Origin: China
Size: 235*165*85mm
Output Frequency: 50HZ/60HZ
Output Type: SINGLE
Customisable: Yes
Output Current: 2.2A/4.4A
Output Power: 801 - 1000KW
Weight: 2.35KG
Model Number: SP-800L
Protection: Low Voltage/Over Voltage, Overload, Over Temperature, Short Circuit
Protection way: LED Alarm and Automatic Recovery
Over Load: Shut Off Output
Over Thermal: Shut Off Output Automatically
Fuses: Short Circuit
Working Temperature: Between -10℃ and +50℃
Start: soft-start
Cooling Way: Intelligent Cooling Fan
Total Harmonic Distortion: THD < 3%
Digital Display: Option
Dear buyer, please note:
When you purchase items that need to be shipped from China, according to international trade rules, you may need to pay import tariffs. Please know your country's tariff policy in advance. Thank you!
① Input voltage: DC 12V/24V/48V (only one voltage can be selected)
② Output voltage: AC 100V/110V/120V/220V/230V/240V (only one voltage can be selected)
③ Output frequency: 50Hz or 60Hz (optional) (only one frequency can be selected)
④ Socket: Universal/US/UK/AU/JP/EU(only one socket can be selected)
|
Model |
sp12/110-800L |
sp24/110-800L |
sp48/110-800L |
sp12/220-800L |
sp24/220-800L |
sp48/220-800L |
|
Continuous Power |
800W |
|||||
|
Surge Power |
1600W |
|||||
|
Frequency |
50HZ±0.5HZ or 60HZ±0.5HZ |
|||||
|
Wave Form |
Pure Sine Wave |
|||||
|
AC Regulation |
THD<3%(Linear Load) |
|||||
|
Output Efficiency |
92% |
|||||
|
DC Voltage |
DC12V |
DC24V |
DC48V |
DC12V |
DC24V |
DC48V |
|
AC Voltage |
100VAC or 110VAC or 120VAC ±5% |
220VAC or 230VAC or 240VAC ±5% |
||||
|
No Load Current Draw |
0.55A |
0.3A |
0.15A |
0.55A |
0.3A |
0.15A |
|
DC Voltage Range |
10-15.5V |
20-31V |
40-61V |
10-15.5V |
20-31V |
40-61V |
|
Low Voltage Alarm |
10.5±0.5V |
21±0.5V |
42±1V |
10.5±0.5V |
21±0.5V |
42±1V |
|
Low Voltage Shut Down |
10±0.5V |
20±0.5V |
40±1V |
10±0.5V |
20±0.5V |
40±1V |
|
Over Voltage Shut Down |
15.5±0.5V |
31±0.5V |
61±1V |
15.5±0.5V |
31±0.5V |
61±1V |
|
Low Voltage Recovery |
13±0.5V |
24±0.5V |
48±1V |
13±0.5V |
24±0.5V |
48±1V |
|
Over Voltage Recovery |
14.8V±0.5V |
29V±0.5V |
59V±1V |
14.8V±0.5V |
29V±0.5V |
59V±1V |
|
Protection |
Low Voltage/Over Voltage |
LED Alarm and Automatic Recovery. |
||||
|
Overload |
LED Alarm |
|||||
|
Over Temperature |
LED Alarm and Automatic Recovery. |
|||||
|
Short Circuit |
LED Alarm and Automatic Recovery. |
|||||
|
Working Temperature |
-10°- +50° |
|||||
|
Storage Temperature |
-30°- +70° |
|||||
|
Production Size |
235*165*85(mm) |
|||||
|
Package Size |
285*155*115(mm) |
|||||
|
N.W/G.W |
2.2/2.8(kg) |
|||||
|
Start |
soft-start |
|||||
|
Qty/Carton |
6 |
|||||
|
Carton Size |
475×370×490 |
|||||
|
Carton Weight |
19.5KG |
|||||
|
Cooling Way |
Intelligent Cooling Fan |
|||||
